Standard joint
HOME>>LAB GLASSWARE>>Standard joint
NO.5074 Adapter with one ground mouth
Product features:Adapter with one ground mouth is a glass instrument commonly used in laboratories. It is mainly composed of a glass tube body and a standard ground mouth. It is generally cylindrical and made of high borosilicate glass. It has good chemical and thermal stability and can withstand certain temperature changes and chemical corrosion. Located at one end of the tube body, the size specifications of the ground mouth follow a unified standard, such as the common 10#, 14#, 19#, etc. This standardized ground mouth design allows the single-mouth tube to be tightly connected with other instruments with the same specification ground mouth, achieving good sealing and stable assembly.

tiandi@tiandicn.com  /  lab-glassware@tiandicn.com

+86-515-88631536  /  +86 13912566435

+ 86 19551521639

Tiandilabware

Product features

Adapter with one ground mouth is a glass instrument commonly used in laboratories. It is mainly composed of a glass tube body and a standard ground mouth. It is generally cylindrical and made of high borosilicate glass. It has good chemical and thermal stability and can withstand certain temperature changes and chemical corrosion. Located at one end of the tube body, the size specifications of the ground mouth follow a unified standard, such as the common 10#, 14#, 19#, etc. This standardized ground mouth design allows the single-mouth tube to be tightly connected with other instruments with the same specification ground mouth, achieving good sealing and stable assembly.

Adapter with one ground mouth has uniform size specifications, strong versatility and interchangeability; it can be effectively sealed with a ground mouth plug to prevent leakage and volatilization; it has good visibility, transparent glass, and is easy to observe the state of the internal material; it is easy to use, simple in structure, convenient to operate, and easy to store and take.

1 英.jpg

Product details

We can produce different adapters as per customer’s requirements.We can also print your logo on the adapters if the quantity is large,please feel free to contact us online.

Product specifications

Item    NO.Ground mouthLength of Upper tube
(mm)
PCS/CTN
507410/19100600
507414/23100600
507419/26100480
507424/29120480
507429/32120320
507434/35120240
507440/38120200
507445/40120200
507450/42120150

Product applications

(1) Reaction type: As a simple reaction container, it can carry out some chemical reactions that do not require high space and equipment, such as acid-base neutralization and precipitation reaction in some solutions.

(2) Storage type: It can store liquid or solid reagents, especially those that are volatile, oxidizable or air-sensitive, and play a role in sealing and preservation.

(3) Connection type: It can be connected with other standard ground-mouth instruments to play a connecting and buffering role in experimental devices such as distillation and absorption.

(4) Sample processing type: It is used to temporarily collect and store samples for subsequent analysis and detection.

1 英.jpg

Previous:NO.5073 Adapter with one stopper
Next:NO.5076 Small mouth and big stopper joint
